去年参加了京东物流优化挑战赛，当时由于要写论文，没有投入太多精力。最近，学习一些机器学习的方法，突然想通过聚类的方式，确定每辆车可选择的客户点的范围，以缩小搜索空间。这里只用kmeans简单的进行了聚类。可以发现，采用不同的标准聚类，结果优较大差异。原来设想的是聚成不同的类后，在装车时每次都从不同的类中选择一个客户点，使得每辆车尽量均匀的包含不同的类中的客户。也可以将每个客户点与其他客户点的距离作为一个特征，采用更复杂的方式处理。但是，要使过程和结果呢具有可解释性，还是要回到运筹优化的方法。

% 经纬度转换load('lon_lat.mat')mstruct = defaultm('mercator');mstruct.geoid = [6378137, 0.0818191908426215];mstruct.origin = [0,0,0];[x,y] = projfwd(mstruct,lon_lat(:,2) ,lon_lat(:,1));% 将配送站设置为中为原点x = x - x(1);   x(1) = [];  y = y - y(1);   y(1) = [];% 求每个客户点的方位角cos_alpha = x./sqrt(x.^2+y.^2);  sin_alpha = y./sqrt(x.^2+y.^2);  cos_sin = [cos_alpha, sin_alpha];

# 观察在新的坐标系下的分布

在新的坐标系下，映射每个客户点的坐标

load('Data/information.mat','Request_info','Distance','Time')Timewindow = Request_info(:,4:5);Timewindow(1001:1100,:) = 960;dis = Distance(:,1);  dis(1) = [];dis_time = Time(:,1); dis_time(1) = [];dis_time = repmat(dis_time,1,2);trans_timewindow_dis = (Timewindow - dis_time);trans_timewindow_dis(1001:1100,1) = 0;startpoint = [trans_timewindow_dis(:,1).*cos_alpha, trans_timewindow_dis(:,1).*sin_alpha];endpoint = [trans_timewindow_dis(:,2).*cos_alpha, trans_timewindow_dis(:,2).*sin_alpha];

绘图

X = [startpoint(:,1), endpoint(:,1)];Y = [startpoint(:,2), endpoint(:,2)];figure(1);clfhold onfor i = 1:1000    line(X(i,:),Y(i,:),'LineWidth',1.2)end% for i = 1001:1100%     line(X(i,:),Y(i,:),'LineWidth',1.2,'Color','g')% endtitle('在新的坐标系下的每个客户点的服务时间')hold off

figure(2);clfhold onfor i = 1:1000    scatter((X(i,1)+X(i,2))/2,(Y(i,1)+Y(i,2))/2,10,'*')endscatter((X(1001:1100,1)+X(1001:1100,2))/2,(Y(1001:1100,1)+Y(1001:1100,2))/2,10,'g*')title('在新的坐标系下的每个客户点的服务时间的中间点')hold off

kmeans 聚类

使用kmeans 聚类对原始坐标和时间窗聚类

Timewindow(1001:1100,:) = repmat([0,960],100,1);Var = [x,y,Timewindow];idx = kmeans(Var(1:1000,:),10);idx(1001:1100) = 0;figure(3);hold on;scatter(0, 0, 20,'rp')scatter(x(idx==0), y(idx==0),15,'g','filled','MarkerFaceAlpha',0.3)legendname{1} = '配送站';legendname{2} = '充电站';for i = 1:10    scatter(x(idx==i), y(idx==i),10,'*','MarkerFaceAlpha',0.8)    legendname{i+2} = ['label=',num2str(i)];endlegend(legendname,'Location','northeastoutside','NumColumns',1)title('直接对原始坐标和时间窗聚类')hold off

对在新坐标系下的点，用kmeans聚类方法得到每个点的标签，然后映射回原始坐标系中

figure(4);clfsubplot(1,2,1);hold onscatter(0, 0,20,'rp')scatter(x(1001:1100), y(1001:1100),15,'g','filled','MarkerFaceAlpha',0.3)scatter(x(1:1000), y(1:1000),10,'b*','MarkerFaceAlpha',0.8)legend({'配送中心','充电站','需求点'})title('贴上标签前')hold offsubplot(1,2,2);hold on;Xc = (X(:,1)+X(:,2))/2;Yc = (Y(:,1)+Y(:,2))/2;idx = kmeans([Xc(1:1000),Yc(1:1000)],10);idx(1001:1100) = 0;scatter(0, 0, 20,'rp')scatter(x(idx==0), y(idx==0),15,'g','filled','MarkerFaceAlpha',0.3)legendname{1} = '配送站';legendname{2} = '充电站';for i = 1:10    scatter(x(idx==i), y(idx==i),10,'*','MarkerFaceAlpha',0.8)    legendname{i+2} = ['label=',num2str(i)];endlegend(legendname,'Location','northoutside','NumColumns',6)title('贴上标签后')hold off
